OEGT AD 2.1 AERODROME LOCATION INDICATOR AND NAME

OEGT - GURIAT

OEGT AD 2.2 AERODROME GEOGRAPHICAL AND ADMINISTRATIVE DATA

1	ARP coordinates and site at AD	N312443 E0371646 NIL
2	Direction and distance from (city)	5 NM SW of town
3	Elevation/Reference temperature	1684 FT / 36° C
4	Geoid undulation at AD ELEV PSN	NIL
5	MAG VAR/Annual change	4° E ( 2015) / 0.07 increasing
6	Aerodrome Operator, address, telephone, telefax, telex, AFS	GENERAL AUTHORITY OF CIVIL AVIATION Guriat Airport Guriat, Saudi Arabia Tel: +966 14 6424664 Fax: +966 14 6425600 Telex: 827049 ICKFAF SJ
7	Types of traffic permitted (IFR/VFR)	IFR/VFR
8	Remarks	Uncontrolled AD. PPR PN 3 HRS to AP for NS.

OEGT AD 2.3 OPERATIONAL HOURS

1	AD Administration	HS SUN - THU 05:00 - 13:00 ( 0800-1600 LMT)
2	Customs and immigration	HO No customs
3	Health and sanitation	NIL
4	AIS Briefing Office	NIL
5	ATS Reporting Office (ARO)	NIL
6	MET Briefing Office	H24
7	ATS	NIL
8	Fuelling	HO
9	Handling	HO
10	Security	H24
11	De-icing	NIL
12	Remarks	Operational hours 04:00-20:00

OEGT AD 2.4 HANDLING SERVICES AND FACILITIES

1	Cargo-handling facilities	HO - Saudi Airlines
2	Fuel/oil types	JET A1 / NIL
3	Fuelling facilities/capacity	Tankers - Delivery rate variable
4	De-icing facilities	NIL
5	Hangar space for visiting aircraft	NIL
6	Repair facilities for visiting aircraft	NIL
7	Remarks	NIL

OEGT AD 2.5 PASSENGER FACILITIES

1	Hotels	In the city
2	Restaurants	Cafeteria
3	Transportation	Taxi
4	Medical facilities	In the Airport
5	Bank and Post Office	In the city / In the Airport
6	Tourist Office	NIL
7	Remarks	NIL

OEGT AD 2.6 RESCUE AND FIRE FIGHTING SERVICES

1	AD category for fire fighting	CAT 6
2	Rescue equipment	Yes
3	Capability for removal of disabled aircraft	NIL
4	Remarks	NIL

OEGT AD 2.7 SEASONAL AVAILABILITY - CLEARING

1	Types of clearing equipment	NIL
2	Clearance priorities	NIL
3	Remarks	NIL

OEGT AD 2.8 APRONS, TAXIWAYS AND CHECK LOCATIONS DATA

Apron surface and strength

Designator	Surface	Strenght
APRON 1	Asphalt	PCN 61/F/A/X/T

Taxiway width, surface and strength

Designator of TWY	Width	Surface	Strenght
TWY 1	27.50 M	Asphalt	PCN 61/F/A/X/T

Altimeter checkpoint location and elevation

NIL

VOR checkpoints

NIL

INS checkpoints

NIL

Remarks

NIL

OEGT AD 2.9 SURFACE MOVEMENT GUIDANCE AND CONTROL SYSTEM AND MARKINGS

1	Use of aircraft stand ID signs, TWY guide lines and visual docking/parking guidance system of aircraft stands	Apron Navigational Marking
2	RWY and TWY markings and LGT	RWY Marking: CL, Edge, THR, ID, TDZ, Pre THR RWY Lighting: EDGE, Runway end, THR TWY Marking: Edge, CL, Holding position TWY Lighting: Edge
3	Stop bars	NIL
4	Other runway protection measures	NIL
5	Remarks	NIL

OEGT AD 2.10 AERODROME OBSTACLES

OBST ID/ Designation	OBST type	OBST position	ELEV/HGT	Markings / Type, colour	Remarks

NIL	NIL	NIL	NIL	NIL	NIL

OEGT AD 2.11 METEOROLOGICAL INFORMATION PROVIDED

1	Associated MET Office	MET STATION GURIAT
2	Hours of service MET Office outside hours	H24 NIL
3	Office responsible for TAF preparation Period of validity	MET OFFICE TABUK 30 HOURS 00,12HR
4	Tred forecast Interval of issuance	TREND 1 Hour
5	Briefing/consultation provided	Self briefing MET OFFICE TABUK Tel: +966 14 421156 Website: https://met.gamep.gov.sa/login/login.php(*)
6	Flight documentation Language(s) used	Charts.abbreviated plain language text. METARs/TAFs available on NCM Website: https://met.gamep.gov.sa/login/login.php English
7	Charts and other information available for briefing or consultation	Significant Weather Charts. SIGMET. AD WARNING available on NCM Website: https://met.gamep.gov.sa/login/login.php
8	Supplementary equipment available for providing information	NIL
9	ATS units provided with information	NIL
10	Additional information (limitation of service, etc.)	+966 14 6425416 (*) Access to NCM website requires user registration.

OEGT AD 2.12 RUNWAY PHYSICAL CHARACTERISTICS

Designations RWY	TRUE BRG	Dimension of RWY (M)	Strength (PCN) and surface of RWY and SWY	THR coordinates RWY end coordinates THR geoid undulation	THR elevation and highest elevation of TDZ of precision APP RWY
1	2	3	4	5	6
10	106.00	3050 x 45	PCN 61/F/A/X/T Asphalt	312457.54N 0371550.89E GUND: NIL	THR 1684.00 FT —
28	286.00	3050 x 45	PCN 61/F/A/X/T Asphalt	312429.47N 0371741.67E GUND: NIL	THR 1653.30 FT TDZ 1659.00 FT

Slope OF RWY and SWY	SWY dimensions (M)	CWY dimensions (M)	Strip dimensions (M)	RESA dimensions (M)	Location and description of engineering material Arresting system (EMAS)	OFZ
7	8	9	10	11	12	13
For Rwy 10: -0.3%	120 x 45	300 x 45	NIL	NIL	NIL	NIL
For Rwy 28: +0.3%	120 x 45	300 x 45	NIL	NIL	NIL	NIL

Remarks
14
NIL
NIL

OEGT AD 2.13 DECLARED DISTANCES

RWY Designator	TORA (M)	TODA (M)	ASDA (M)	LDA (M)	Remarks
1	2	3	4	5	6
10	3050	3350	3170	3050	NIL
28	3050	3350	3170	3050	NIL

OEGT AD 2.14 APPROACH AND RUNWAY LIGHTING

RWY Designator	APCH LGT type LEN INTST	THR LGT colour WBAR	VASIS (MEHT) PAPI	TDZ, LGT LEN	RWY Centre Line LGT Length, spacing, colour, INTST	RWY edge LGT LEN, spacing colour INTST	RWY End LGT colour WBAR	SWY LGT LEN (M) colour	Remarks
1	2	3	4	5	6	7	8	9	10
10	NIL	LIM Green	PAPI Both sides/3°	NIL	NIL	3050 M, 60 M White LIH	Red Light intensity medium	NIL	NIL
28	SALS 420 M LIH	LIM Green	PAPI Both sides/3°	NIL	NIL	3050 M, 60 M White LIH	Red Light intensity medium	NIL	NIL

OEGT AD 2.15 OTHER LIGHTING, SECONDARY POWER SUPPLY

ABN/IBN location, characteristics and hours of operation

ABN : ALTN Green White: SS-SR and O/R

LDI location and LGT Anemometer location and LGT

LDI: NIL
Anemometer: LGTD

TWY edge and centre line lighting and stop bars (if any)

Taxiway Edge:

NIL

Taxiway centre line:

NIL

Secondary power supply/switch-over time

07 SEC

Remarks

NIL

OEGT AD 2.16 HELICOPTER LANDING AREA

Coordinates TLOF or THR of FATO
Geoid undulation

NIL
NIL

TLOF and/or FATO elevation M/FT

NIL

TLOF and FATO area dimensions, surface, strength, marking

NIL

True BRG of FATO

NIL

Declared distance available

NIL

APP and FATO lighting

NIL

Remarks

NIL

OEGT AD 2.17 ATS AIRSPACE

Designation and lateral limits

GURIAT ATZ

Circle with radius of 5NM centered on 312443N 0371646E.

Vertical limits

SFC to 4500 FT AMSL

Airspace classification

ATS unit call sign Language(s)

Saudia Radio Guriat
Arabic/English

Transition altitude

13000 FT

Hours of applicability (or activation)

NIL

Remarks

NIL

OEGT AD 2.18 ATS COMMUNICATION FACILITIES

Service designation	Call sign	Frequency	Hours of operation	SATVOICE	Logon address	Remarks
1	2	3	4	5	6	7
RADIO	GURIAT TIBA	122.800 MHZ	H24	NIL	NIL	TIBA procedure must be followed . Call FRS 15 MIN before ARR time on FREQ 133.500 MHZ

OEGT AD 2.19 RADIO NAVIGATION AND LANDING AIDS

Type of aid MAG VAR Type of supported OPS (for VOR/ILS/MLS, give declination)	ID	Frequency	Hours of operation	Position of transmitting antenna coordinates	Elevation of DME transmitting antenna	Service volume radius from GBAS reference Point	Remarks
1	2	3	4	5	6	7	8
LOC 28 ILS CAT I	IGRY	110.900 MHZ	H24	312500.3N 0371540.0E	NIL	NIL	NIL
GP 28 ILS CAT I	IGRY	330.800 MHZ	H24	312428.5N 0371729.5E	NIL	NIL	GPA 3° RDH 54.7 FT
DME 28 ILS CAT I	IGRY	(CH46X)	H24	312428.5N 0371729.5E	1700 FT	NIL	DME reads Zero at the DME antenna
VOR/TACAN (05° E)	GRY	114.700 MHZ (CH94X)	H24	312445.5N 0371711.6E	1700 FT	NIL	NIL

OEGT AD 2.20 LOCAL AERODROME REGULATIONS

2.20.1 Parking area

PRKG PSN 1 restricted to E-170 or smaller ACFT.
PRKG PSN 2 restricted to AD REF Code C or smaller ACFT.
PRKG PSN 3 restricted to AD REF Code D or smaller ACFT.
AD REF Code D ACFT not allowed to leave PRKG PSN 3 if AD REF Code C ACFT parked at PRKG PSN 2.

OEGT AD 2.21 NOISE ABATEMENT PROCEDURES

NIL

OEGT AD 2.22 FLIGHT PROCEDURES

NIL

OEGT AD 2.23 ADDITIONAL INFORMATION

NIL

OEGT AD 2.24 CHARTS RELATED TO AN AERODROME

Charts	Pages
Aerodrome Chart - ICAO
Instrument Approach Chart - ICAO (ILS-DME RWY 28)
ILS-DME RWY 28 (aeronautical data tabulation)
Instrument Approach Chart - ICAO (VOR-DME RWY 28)
VOR-DME RWY 28 (aeronautical data tabulation)
Instrument Approach Chart - ICAO (VOR RWY 10)
VOR RWY 10 (aeronautical data tabulation)
Instrument Approach Chart - ICAO (VOR RWY 28)
VOR RWY 28 (aeronautical data tabulation)
