OEST AD 2.1 AERODROME LOCATION INDICATOR AND NAME
|
|
|
|
OEST AD 2.2 AERODROME GEOGRAPHICAL AND ADMINISTRATIVE DATA
|
|
1
|
ARP coordinates and site at AD
|
N224232 E0531705
213° / 117 NM FM VAH 230° / 155 NM FM ALN
|
2
|
Direction and distance from (city)
|
NIL
|
3
|
Elevation/Reference temperature
|
342 FT / 45° C
|
4
|
Geoid undulation at AD ELEV PSN
|
NIL
|
5
|
MAG VAR/Annual change
|
1° E ( 2010)
|
6
|
Aerodrome Operator, address, telephone, telefax, telex, AFS
|
BORDER GUARD
Riyadh 11135
Saudi Arabia
|
7
|
Types of traffic permitted (IFR/VFR)
|
IFR/VFR
|
8
|
Remarks
|
NIL
|
|
OEST AD 2.3 OPERATIONAL HOURS
|
|
1
|
AD Administration
|
HX
|
2
|
Customs and immigration
|
NIL
|
3
|
Health and sanitation
|
NIL
|
4
|
AIS Briefing Office
|
NIL
|
5
|
ATS Reporting Office (ARO)
|
NIL
|
6
|
MET Briefing Office
|
NIL
|
7
|
ATS
|
NIL
|
8
|
Fuelling
|
NIL
|
9
|
Handling
|
NIL
|
10
|
Security
|
NIL
|
11
|
De-icing
|
NIL
|
12
|
Remarks
|
NIL
|
|
OEST AD 2.4 HANDLING SERVICES AND FACILITIES
|
|
1
|
Cargo-handling facilities
|
NIL
|
2
|
Fuel/oil types
|
NIL / NIL
|
3
|
Fuelling facilities/capacity
|
NIL
|
4
|
De-icing facilities
|
NIL
|
5
|
Hangar space for visiting aircraft
|
NIL
|
6
|
Repair facilities for visiting aircraft
|
NIL
|
7
|
Remarks
|
NIL
|
|
OEST AD 2.5 PASSENGER FACILITIES
|
|
1
|
Hotels
|
NIL
|
2
|
Restaurants
|
NIL
|
3
|
Transportation
|
NIL
|
4
|
Medical facilities
|
NIL
|
5
|
Bank and Post Office
|
NIL
|
6
|
Tourist Office
|
NIL
|
7
|
Remarks
|
NIL
|
|
OEST AD 2.6 RESCUE AND FIRE FIGHTING SERVICES
|
|
1
|
AD category for fire fighting
|
NIL
|
2
|
Rescue equipment
|
NIL
|
3
|
Capability for removal of disabled aircraft
|
NIL
|
4
|
Remarks
|
NIL
|
|
OEST AD 2.7 SEASONAL AVAILABILITY - CLEARING
|
|
1
|
Types of clearing equipment
|
NIL
|
2
|
Clearance priorities
|
NIL
|
3
|
Remarks
|
NIL
|
|
OEST AD 2.8 APRONS, TAXIWAYS AND CHECK LOCATIONS DATA
|
|
1
|
Apron surface and strength
|
APRON
|
Concrete
|
PCN 65/F/A/X/T
|
|
2
|
Taxiway width, surface and strength
|
TWY
|
15.00 M
|
Concrete
|
PCN 65/F/A/X/T
|
|
3
|
Altimeter checkpoint location and elevation
|
NIL
|
4
|
VOR checkpoints
|
|
5
|
INS checkpoints
|
|
6
|
Remarks
|
NIL
|
|
OEST AD 2.9 SURFACE MOVEMENT GUIDANCE AND CONTROL SYSTEM AND MARKINGS
|
|
1
|
Use of aircraft stand ID signs, TWY guide lines and visual docking/parking guidance system of aircraft stands
|
NIL
|
2
|
RWY and TWY markings and LGT
|
RWY: CL, END, Basic RWY marking
|
3
|
Stop bars
|
NIL
|
4
|
Other runway protection measures
|
NIL
|
5
|
Remarks
|
NIL
|
|
OEST AD 2.10 AERODROME OBSTACLES
|
|
|
In approach/TKOF areas
|
In circling area and at AD
|
Remarks
|
|
1
|
2
|
3
|
|
RWY NR/Area affected
|
Obstacle type
Elevation
Markings/LGT
|
Coordinates
|
Obstacle type
Elevation
Markings/LGT
|
Coordinates
|
High sand dunes 5NM/15KM of RWY APCH to 13/31 sand 3.33% penetrate 2% climb both RWY
|
|
a
|
b
|
c
|
a
|
b
|
|
13/31
|
Sand dunes
|
NIL |
NIL
|
NIL |
- |
|
OEST AD 2.11 METEOROLOGICAL INFORMATION PROVIDED
|
|
1
|
Associated MET Office
|
NIL
|
2
|
Hours of service
MET Office outside hours
|
NIL
|
3
|
Office responsible for TAF preparation
Period of validity
|
NIL
|
4
|
Tred forecast
Interval of issuance
|
NIL
|
5
|
Briefing/consultation provided
|
NIL
|
6
|
Flight documentation
Language(s) used
|
NIL
|
7
|
Charts and other information available for briefing or consultation
|
NIL
|
8
|
Supplementary equipment available for providing information
|
NIL
|
9
|
ATS units provided with information
|
NIL
|
10
|
Additional information (limitation of service, etc.)
|
Terminal weather data ( AWOS ) reported on ATIS FREQ.
|
|
OEST AD 2.12 RUNWAY PHYSICAL CHARACTERISTICS
|
|
Designations RWY
|
TRUE BRG
|
Dimension of RWY (M)
|
Strength (PCN) and surface of RWY and SWY
|
THR coordinates
RWY end coordinates
THR geoid undulation
|
THR elevation and highest elevation of TDZ of precision APP RWY
|
1
|
2
|
3
|
4
|
5
|
6
|
13
|
128.00
|
2100 x 30
|
PCN 54/R/C/W/T
Concrete
|
224255.03N
0531625.71E
GUND: NIL
|
THR 341.00 FT
TDZ 342.46 FT
|
31
|
308.00
|
2100 x 30
|
PCN 54/R/C/W/T
Concrete
|
224212.83N
0531723.55E
GUND: NIL
|
THR 330.00 FT
TDZ 342.46 FT
|
|
Slope OF RWY and SWY
|
SWY dimensions (M)
|
CWY dimensions (M)
|
Strip dimensions (M)
|
RESA dimensions (M)
|
Location and
description of
engineering
material
Arresting system
(EMAS)
|
OFZ
|
7
|
8
|
9
|
10
|
11
|
12
|
13
|
For Rwy 13: NIL
|
NIL
|
NIL
|
NIL
|
NIL
|
NIL
|
NIL
|
For Rwy 31: NIL
|
NIL
|
NIL
|
NIL
|
NIL
|
NIL
|
NIL
|
|
Remarks
|
14
|
NIL
|
DTHR 224221.51N 0531711.65E
|
|
OEST AD 2.13 DECLARED DISTANCES
|
|
RWY Designator
|
TORA
(M)
|
TODA
(M)
|
ASDA
(M)
|
LDA
(M)
|
Remarks
|
1
|
2
|
3
|
4
|
5
|
6
|
13
|
NIL
|
NIL
|
NIL
|
NIL
|
NIL
|
31
|
NIL
|
NIL
|
NIL
|
NIL
|
NIL
|
|
OEST AD 2.14 APPROACH AND RUNWAY LIGHTING
|
|
RWY
Designator
|
APCH LGT type LEN INTST
|
THR LGT colour WBAR
|
VASIS (MEHT) PAPI
|
TDZ, LGT LEN
|
RWY Centre Line LGT Length, spacing, colour, INTST
|
RWY edge LGT LEN, spacing colour INTST
|
RWY End LGT colour WBAR
|
SWY LGT LEN (M) colour
|
Remarks
|
1
|
2
|
3
|
4
|
5
|
6
|
7
|
8
|
9
|
10
|
13
|
NIL
|
Green
|
PAPI
|
NIL
|
NIL
|
MIRL
|
Red
|
NIL
|
NIL
|
31
|
NIL
|
Green
|
PAPI
|
NIL
|
NIL
|
MIRL
|
Red
|
NIL
|
NIL
|
|
OEST AD 2.15 OTHER LIGHTING, SECONDARY POWER SUPPLY
|
|
1
|
ABN/IBN location, characteristics and hours of operation
|
|
2
|
LDI location and LGT Anemometer location and LGT
|
LDI: NIL
Anemometer: NIL
|
3
|
TWY edge and centre line lighting and stop bars (if any)
|
Taxiway Edge:
|
NIL
|
Taxiway centre line:
|
NIL
|
|
4
|
Secondary power supply/switch-over time
|
NIL
|
5
|
Remarks
|
NIL
|
|
OEST AD 2.16 HELICOPTER LANDING AREA
|
|
1
|
Coordinates TLOF or THR of FATO
Geoid undulation
|
|
2
|
TLOF and/or FATO elevation M/FT
|
|
3
|
TLOF and FATO area dimensions, surface, strength, marking
|
|
4
|
True BRG of FATO
|
NIL
|
5
|
Declared distance available
|
NIL
|
6
|
APP and FATO lighting
|
|
7
|
Remarks
|
NIL
|
|
OEST AD 2.17 ATS AIRSPACE
|
|
1
|
Designation and lateral limits
|
SHABITAH ATZ
|
Circle with radius of 5NM centered on 224232N 0531705E.
|
|
2
|
Vertical limits
|
|
3
|
Airspace classification
|
|
4
|
ATS unit call sign Language(s)
|
|
5
|
Transition altitude
|
13000 FT
|
6
|
Hours of applicability (or activation)
|
|
7
|
Remarks
|
TIBA 122.800 MHZ RADIO 127.000 MHZ
|
|
|
OEST AD 2.18 ATS COMMUNICATION FACILITIES
|
|
Service designation
|
Call sign
|
Frequency
|
Hours of operation
|
SATVOICE
|
Logon address
|
Remarks
|
1
|
2
|
3
|
4
|
5
|
6
|
7
|
ATIS
|
SHABITAH
INFORMATION
INFORMATION.
|
NIL
126.350 MHZ
|
H24
NIL
|
NIL
|
NIL
|
NIL
|
SHABITAH INFORMATION
|
126.350 MHZ
|
H24
|
NIL
|
RADIO
|
SHABITAH TWR
|
127.000 MHZ
|
NIL
|
NIL
|
NIL
|
NIL
|
TIBA
|
NIL
|
122.800 MHZ
|
NIL
|
NIL
|
NIL
|
NIL
|
|
OEST AD 2.19 RADIO NAVIGATION AND LANDING AIDS
|
|
Type of aid
MAG VAR
Type of
supported OPS
(for
VOR/ILS/MLS,
give declination)
|
ID
|
Frequency
|
Hours of operation
|
Position of transmitting antenna coordinates
|
Elevation of DME transmitting antenna
|
Service
volume
radius
from GBAS
reference
Point
|
Remarks
|
1
|
2
|
3
|
4
|
5
|
6
|
7
|
8
|
DVOR/DME
(02° E)
|
SBT
|
115.100 MHZ
(CH98X)
|
H24
|
224244.9N
0531646.1E
|
400 FT
|
NIL
|
NIL
|
|
OEST AD 2.20 LOCAL AERODROME REGULATIONS
|
|
|
|
OEST AD 2.21 NOISE ABATEMENT PROCEDURES
|
|
|
|
OEST AD 2.22 FLIGHT PROCEDURES
|
|
|
|
OEST AD 2.23 ADDITIONAL INFORMATION
|
|
|
|
OEST AD 2.24 CHARTS RELATED TO AN AERODROME
|
|
Charts
|
Pages
|
Aerodrome Chart - ICAO
|
|
Instrument Approach Chart - ICAO (VOR-DME RWY 13)
|
|
VOR-DME RWY 13 (aeronautical data tabulation)
|
|
Instrument Approach Chart - ICAO (VOR-DME RWY 31)
|
|
VOR-DME RWY 31 (aeronautical data tabulation)
|
|
|
|
|
