OESN AD 2.1 AERODROME LOCATION INDICATOR AND NAME

OESN - KING SALMAN AIRBASE

OESN AD 2.2 AERODROME GEOGRAPHICAL AND ADMINISTRATIVE DATA

1	ARP coordinates and site at AD	N242806 E0463901 1048 M / 028 GEO from KSN VOR/DME, between RWY 02R/20L and RWY 02L/02R
2	Direction and distance from (city)	24 KM Southwest of Riyadh city
3	Elevation/Reference temperature	2450 FT / 42° C
4	Geoid undulation at AD ELEV PSN	-25 FT
5	MAG VAR/Annual change	3° E ( 2025)
6	Aerodrome Operator, address, telephone, telefax, telex, AFS	MILITARY KING SALMAN AIRBASE Riyadh 14773 Saudi Arabia Tel: +966 11 3645760 (TWR) Fax: +966 11 4917728
7	Types of traffic permitted (IFR/VFR)	IFR/VFR
8	Remarks	Controled Military AD

OESN AD 2.3 OPERATIONAL HOURS

1	AD Administration	H24
2	Customs and immigration	H24
3	Health and sanitation	H24
4	AIS Briefing Office	H24
5	ATS Reporting Office (ARO)	H24
6	MET Briefing Office	H24
7	ATS	H24
8	Fuelling	H24
9	Handling	By arrangement
10	Security	H24
11	De-icing	NIL
12	Remarks	NIL

OESN AD 2.4 HANDLING SERVICES AND FACILITIES

1	Cargo-handling facilities	NIL
2	Fuel/oil types	JET A1 , AVGAS , JP8 / NIL
3	Fuelling facilities/capacity	Tankers - Delivery rate variable
4	De-icing facilities	NIL
5	Hangar space for visiting aircraft	NIL
6	Repair facilities for visiting aircraft	NIL
7	Remarks	NIL

OESN AD 2.5 PASSENGER FACILITIES

1	Hotels	NIL
2	Restaurants	NIL
3	Transportation	NIL
4	Medical facilities	NIL
5	Bank and Post Office	NIL
6	Tourist Office	NIL
7	Remarks	NIL

OESN AD 2.6 RESCUE AND FIRE FIGHTING SERVICES

1	AD category for fire fighting	CAT 9
2	Rescue equipment	7 Major foam Tenders 1 fire Command Vehicle 1 Forward Command Vehicle 1 Water Tanker 1 Rescue Stairs
3	Capability for removal of disabled aircraft	NIL
4	Remarks	NIL

OESN AD 2.7 SEASONAL AVAILABILITY - CLEARING

1	Types of clearing equipment	NIL
2	Clearance priorities	NIL
3	Remarks	NIL

OESN AD 2.8 APRONS, TAXIWAYS AND CHECK LOCATIONS DATA

Apron surface and strength

Designator	Surface	Strenght
APRON	Concrete and asphalt	NIL
Helipad Apron	Concrete and asphalt	NIL

Taxiway width, surface and strength

Designator of TWY	Width	Surface	Strenght
A	23.00 M	Asphalt	NIL
A1	23.00 M	Asphalt	NIL
A2	23.00 M	Asphalt	NIL
A3	23.00 M	Asphalt	NIL
A4	23.00 M	Asphalt	NIL
A5	23.00 M	Asphalt	NIL
A6	23.00 M	Asphalt	NIL
B	23.00 M	Asphalt	NIL
B1	36.00 M	Asphalt	NIL
B2	39.00 M	Asphalt	NIL
B3	36.00 M	Asphalt	NIL
C	23.00 M	Asphalt	NIL
C1	23.00 M	Asphalt	NIL
C2	23.00 M	Asphalt	NIL
C3	23.00 M	Asphalt	NIL
C4	23.00 M	Asphalt	NIL
D	15.00 M	Asphalt	NIL
G	23.00 M	Asphalt	NIL
G1	23.00 M	Asphalt	NIL
G2	23.00 M	Asphalt	NIL
G3	23.00 M	Asphalt	NIL
G4	23.00 M	Asphalt	NIL
G5	23.00 M	Asphalt	NIL

Altimeter checkpoint location and elevation

Refer to ACFT Parking/ Docking Chart

VOR checkpoints

NIL

INS checkpoints

NIL

Remarks

NIL

OESN AD 2.9 SURFACE MOVEMENT GUIDANCE AND CONTROL SYSTEM AND MARKINGS

1	Use of aircraft stand ID signs, TWY guide lines and visual docking/parking guidance system of aircraft stands	Apron marking and signs
2	RWY and TWY markings and LGT	RWY Marking: CL, Side Stripe, ID, THR, TDZ RWY Lighting: Edge, Rwnway end and THR All TWY Marking: CL, Edge, Holding position All TWY Lighting: Edgem Guidance signs
3	Stop bars	NIL
4	Other runway protection measures	NIL
5	Remarks	NIL

OESN AD 2.10 AERODROME OBSTACLES

OBST ID/ Designation	OBST type	OBST position	ELEV/HGT	Markings / Type, colour	Remarks
https://aimss.sans.com.sa/assets/FileManagerFiles/eTOD/Obstacle/Aerodromes/OESN/OESN-Obstacles.xlsx
https://aimss.sans.com.sa/assets/FileManagerFiles/eTOD/Obstacle/Aerodromes/OESN/OESN-Obstacles.pdf

OESN AD 2.11 METEOROLOGICAL INFORMATION PROVIDED

1	Associated MET Office	RIYADH MET OFFICE
2	Hours of service MET Office outside hours	24H
3	Office responsible for TAF preparation Period of validity	JEDDAH CENTRAL FORECAST OFFICE (CFO) (TAF periods of validity H30) TEL: 02 653 2173 and 02 653 2197 FAX: 02 653 0197
4	Tred forecast Interval of issuance	TEND Routine
5	Briefing/consultation provided	P,T
6	Flight documentation Language(s) used	C, PL English
7	Charts and other information available for briefing or consultation	S, U, P, W
8	Supplementary equipment available for providing information	NIL
9	ATS units provided with information	KING SALMAN TWR
10	Additional information (limitation of service, etc.)	NIL

OESN AD 2.12 RUNWAY PHYSICAL CHARACTERISTICS

Designations RWY	TRUE BRG	Dimension of RWY (M)	Strength (PCN) and surface of RWY and SWY	THR coordinates RWY end coordinates THR geoid undulation	THR elevation and highest elevation of TDZ of precision APP RWY
1	2	3	4	5	6
02L	025.00	3301 x 45	PCN 80/F/A/W/T Concrete and asphalt	242717.38N 0463815.39E GUND: -25 FT	THR 2449.57 FT TDZ 2450.00 FT
20R	205.00	3301 x 45	PCN 80/F/A/W/T Concrete and asphalt	242854.62N 0463904.92E GUND: -25 FT	THR 2280.03 FT TDZ 2401.00 FT
02R	025.00	4000 x 45	PCN 80/F/A/W/T Concrete and asphalt	242711.67N 0463858.52E GUND: -25 FT	THR 2407.99 FT TDZ 2406.00 FT
20L	205.00	4000 x 45	PCN 80/F/A/W/T Concrete and asphalt	242909.50N 0463958.55E GUND: -25 FT	THR 2324.50 FT TDZ 2335.00 FT

Slope OF RWY and SWY	SWY dimensions (M)	CWY dimensions (M)	Strip dimensions (M)	RESA dimensions (M)	Location and description of engineering material Arresting system (EMAS)	OFZ
7	8	9	10	11	12	13
For Rwy 02L: -0.64%	NIL	NIL	3421 x 280	240 x 150	NIL	NIL
For Rwy 20R: +0.64%	NIL	NIL	3421 x 280	240 x 150	NIL	NIL
For Rwy 02R: -0.65%	NIL	NIL	4120 x 280	300 x 150	NIL	NIL
For Rwy 20L: +0.65%	NIL	NIL	4120 x 280	300 x 150	NIL	NIL

Remarks
14
DTHR 02L N 242720.35 E 0463816.91 DTHR 2449.3 FT TDZ 2450 FT
NIL
DTHR 02R N 242726.40 E 046 3906.02 DTHR 2409.69 FT TDZ 2406 FT
NIL

OESN AD 2.13 DECLARED DISTANCES

RWY Designator	TORA (M)	TODA (M)	ASDA (M)	LDA (M)	Remarks
1	2	3	4	5	6
02L	3301	3301	3301	3201	NIL
20R	3301	3301	3301	3301	NIL
02R	4000	4000	4000	3500	NIL
20L	4000	4000	4000	4000	NIL

OESN AD 2.14 APPROACH AND RUNWAY LIGHTING

RWY Designator	APCH LGT type LEN INTST	THR LGT colour WBAR	VASIS (MEHT) PAPI	TDZ, LGT LEN	RWY Centre Line LGT Length, spacing, colour, INTST	RWY edge LGT LEN, spacing colour INTST	RWY End LGT colour WBAR	SWY LGT LEN (M) colour	Remarks
1	2	3	4	5	6	7	8	9	10
02L	CAT1 831 M LIH	Green	PAPI 3°	NIL	NIL	Hi Bidirectional Yellow/White	Red	NIL	NIL
20R	SIMPLE 300 M LIH	Green	PAPI 3°	NIL	NIL	Hi Bidirectional Yellow/White	Red	NIL	NIL
02R	CAT1 900 M LIH	Green	PAPI 3°	NIL	NIL	Hi Bidirectional Yellow/White	Red	NIL	NIL
20L	SIMPLE 420 M LIH	Green	PAPI 3°	NIL	NIL	Hi Bidirectional Yellow/White	Red	NIL	NIL

OESN AD 2.15 OTHER LIGHTING, SECONDARY POWER SUPPLY

ABN/IBN location, characteristics and hours of operation

ABN : ABN: Located at the top of the ATC Tower.
Color: White/White/Green
Ops: 24H

LDI location and LGT Anemometer location and LGT

LDI: AWOS is available
Anemometer: NIL

TWY edge and centre line lighting and stop bars (if any)

Taxiway Edge:

A - Blue
A1 - Blue
A2 - Blue
A3 - Blue
A4 - Blue
A5 - Blue
A6 - Blue
B - Blue
B1 - Blue
B2 - Blue
C1 - Blue
C2 - Blue
C3 - Blue
C4 - Blue
D - Blue
G - Blue
G1 - Blue
G2 - Blue
G3 - Blue
G4 - Blue
G5 - Blue

Taxiway centre line:

NIL

Secondary power supply/switch-over time

15 sec is the switching Transformer to Generator

Remarks

NIL

OESN AD 2.16 HELICOPTER LANDING AREA

Coordinates TLOF or THR of FATO
Geoid undulation

KING SALMAN FATO
N 24 27 02.00 E 046 39 16.00

KING SALMAN TOLF
N 24 27 02.00 E 046 39 16.00

TLOF and/or FATO elevation M/FT

KING SALMAN FATO	2386 FT
KING SALMAN TOLF	2386 FT

TLOF and FATO area dimensions, surface, strength, marking

KING SALMAN FATO	97x97 FT, Concrete, Triangle Mark
KING SALMAN TOLF	75x75 FT, , Triangle Mark

True BRG of FATO

NIL

Declared distance available

NIL

APP and FATO lighting

KING SALMAN FATO	Omnidirectional light
KING SALMAN TOLF	Omnidirectional light

Remarks

NIL

OESN AD 2.17 ATS AIRSPACE

Designation and lateral limits

KING SALMAN CTR

Circle with radius of 3NM centered on 242806N 0463901E.

Vertical limits

SFC to 4000 FT AMSL

Airspace classification

ATS unit call sign Language(s)

SALMAN Tower
English

Transition altitude

13000 FT

Hours of applicability (or activation)

H24

Remarks

Civil and Military Aerodrome Control Service

OESN AD 2.18 ATS COMMUNICATION FACILITIES

Service designation	Call sign	Frequency	Hours of operation	SATVOICE	Logon address	Remarks
1	2	3	4	5	6	7
TWR	SALMAN Tower	118.100 MHZ	H24	NIL	NIL	NIL
TWR	SALMAN Tower	341.600 MHZ	H24	NIL	NIL	NIL
SMC	SALMAN GROUND	121.900 MHZ	H24	NIL	NIL	Ground Control
SMC	SALMAN GROUND	262.500 MHZ	H24	NIL	NIL	Ground Control
ATIS	ARR	133.500 MHZ	H24	NIL	NIL	ATIS Service
ATIS	DEP	133.600 MHZ	H24	NIL	NIL	ATIS Service

OESN AD 2.19 RADIO NAVIGATION AND LANDING AIDS

Type of aid MAG VAR Type of supported OPS (for VOR/ILS/MLS, give declination)	ID	Frequency	Hours of operation	Position of transmitting antenna coordinates	Elevation of DME transmitting antenna	Service volume radius from GBAS reference Point	Remarks
1	2	3	4	5	6	7	8
LOC 02L ILS CAT I	KSND	111.100 MHZ	H24	242903.7N 0463909.6E	NIL	NIL	Height of counterpoise 5.1m
GP 02L ILS CAT I	KSND	331.700 MHZ	H24	242731.0N 0463817.6E	NIL	NIL	ANGLE 3° RDH 50 FT
DME 02L ILS CAT I	KSND	(CH48X)	H24	242731.0N 0463817.6E	2500 FT	NIL	Co-Located with GP DME reads Zero at the DME antenna DME elevation 2450 FT
LOC 02R ILS CAT I	ISND	111.950 MHZ	H24	242918.0N 0464002.9E	NIL	NIL	NIL
GP 02R ILS CAT I	ISND	330.950 MHZ	H24	242737.2N 0463906.8E	NIL	NIL	ANGLE 3° RDH 50 FT
DME 02R ILS CAT I	ISND	112.700 MHZ (CH56Y)	H24	242737.2N 0463906.8E	2500 FT	NIL	Co-Located with GP DME reads Zero at the DME antenna DME elevation 2420 FT
DVOR/TACAN (03° E)	KSN	112.700 MHZ (CH74X)	H24	242836.1N 0463918.3E	2400 FT	NIL	NIL

OESN AD 2.20 LOCAL AERODROME REGULATIONS

OESN AD 2.21 NOISE ABATEMENT PROCEDURES

OESN AD 2.22 FLIGHT PROCEDURES

2.22.1 Holding procedures

KS101 holding and missed approach holding AT 6000 FT for RWY 02L/20R
KS101 holding and missed approach holding AT 6000 FT for RWY 02R/20L.
KSN VOR holding and missed approach holding AT 6000 FT for RWY 02L/20R
KSN VOR holding and missed approach holding AT 6000 FT for RWY 02R/20L.

2.22.2 Approach facilities:

The following approach facilities are available at King Salman Airbase:

RNP Approaches for RWY 02L/20R and RWY 02R/20L.
ILS Approaches for RWY 02L and RWY 02R
RNP to ILS approach RWY 02R
VOR Approaches for RWY 02L and RWY 02R/20L.

The associated instrument approach procedure can be found in the relevant Instrument Approach Charts.

2.22.3 Circuit directions

Aircraft operate on visual traffic circuit east of RWY 02L/20R and RWY 02R/20L.

2.22.4 Departure procedures

OMNI DEP 1C RWY 02L (OMNIDIRECTIONAL DEPARTURE ONE CHARLIE 02L)
ROUTE	RESTRICTION	CLIMB TO
Climb on RWY heading to 3600 ft or above. Continue as per ATC Clearance received before take-off. Right turn may be initiated by ATC after passing 3600 ft.	Turn before DER is not allowed. Turn right must be initiated after takeoff to avoid OEP37. Required PDG 6.5% after reaching 3600 ft.	6000 ft.

OMNI DEP 1B RWY 20R (OMNIDIRECTIONAL DEPARTURE ONE BRAVO 20R)
ROUTE	RESTRICTION	CLIMB TO
Climb on RWY heading to 3500 ft or above. Continue as per ATC Clearance received before take-off. Left turn may be initiated by ATC after passing 3500 ft.	Turn before DER is not allowed.	6000 ft.

OMNI DEP 1D RWY 02R (OMNIDIRECTIONAL DEPARTURE ONE DELTA 02R)
ROUTE	RESTRICTION	CLIMB TO
Climb on RWY heading to 3600 ft or above. Continue as per ATC Clearance received before take-off. Right turn may be initiated by ATC after passing 3600 ft.	Turn before DER is not allowed. Turn right must be initiated after takeoff to avoid OEP37. Required PDG 7.6% after reaching 3600 ft.	6000 ft.

OMNI DEP 1A RWY 20L (OMNIDIRECTIONAL DEPARTURE ONE ALPHA 02L)
ROUTE	RESTRICTION	CLIMB TO
Climb on RWY heading to 3600 ft or above. Continue as per ATC Clearance received before take-off. Left turn may be initiated by ATC after passing 3600 ft.	Turn before DER is not allowed.	6000 ft.

OESN AD 2.23 ADDITIONAL INFORMATION

OESN AD 2.24 CHARTS RELATED TO AN AERODROME

Charts	Pages
Aerodrome Chart - ICAO
Aerodrome Obstacle Chart - ICAO Type A (RWY 02L-20R)
Aerodrome Obstacle Chart - ICAO Type A (RWY 02R-20L)
Aerodrome Obstacle Chart - ICAO Type B
Aircraft Parking-Docking Chart - ICAO
Instrument Approach Chart - ICAO (RNP RWY 02L)
RNP RWY 02L (aeronautical data tabulation)
Instrument Approach Chart - ICAO (RNP RWY 02R)
RNP RWY 02R (aeronautical data tabulation)
Instrument Approach Chart - ICAO (RNP RWY 20L)
RNP RWY 20L (aeronautical data tabulation)
Instrument Approach Chart - ICAO (RNP RWY 20R)
RNP RWY 20R (aeronautical data tabulation)
Instrument Approach Chart - ICAO (ILS Y RWY 02R)
ILS Y RWY 02R (aeronautical data tabulation)
Instrument Approach Chart - ICAO (ILS Z or LOC RWY 02R)
ILS Z or LOC RWY 02R (aeronautical data tabulation)
Instrument Approach Chart - ICAO (ILS or LOC RWY 02L)
ILS or LOC RWY 02L (aeronautical data tabulation)
Instrument Approach Chart - ICAO (VOR RWY 02L)
VOR RWY 02L (aeronautical data tabulation)
Instrument Approach Chart - ICAO (VOR RWY 02R)
VOR RWY 02R (aeronautical data tabulation)
Instrument Approach Chart - ICAO (VOR RWY 20L)
VOR RWY 20L (aeronautical data tabulation)
